15W/8530K00

15cm Midwoofer 8ohm, Coated Sliced Paper Cone, Large Ferrite Magnet

Category: Tags: ,

The Revelator midrange and midwoofers, both well known for their sliced paper cone technology. The slices are filled with damping glue, which dramatically reduces break-up modes in the diaphragm. In combination with Scan-Speaks low-loss linear suspension and the patented Symmetrical Drive (SD-1) it represented a breakthrough in midrange clarity and overall smooth frequency response characteristics.

DIY Kits:
Ellam-XT (R2904/7000, 15W/8530K00)
Ellam FLEX 3W (D3004/660000 or R3004/662000, 15W/8530K00, 22W/4851T00)
Ellam Flex (D3004/660000 or R3004/662000, 15W/8530K00)
Ellam Dappo (R2604/832000 / D2904/980000, 15W/8530-K00)
Ellam 98 mkII (D2904/980000, 15W/8530-K00)






Weight 1.9 kg
Product Families

Revelator

Product Categories

Midwoofer


- Patented Symmetrical Drive Motor Design
- Sliced Cone (Controls Cone Breakups)
- Low-Loss linear suspension
- Low Damping SBR Rubber Surround
- Coated Paper Cone
- Large Ferrite Magnet System

  Size:15 cm
  Fs:39 Hz
  Re:5.9 Ω
  Qt:0.39
  Sensitivity:86 dB
  VAS:16 ltr.
  Sd:95 cm²
  Bl:6.6 Tm
