18WE/4542T00

18 cm Midwoofer, 4 ohm, Paper Cone, Neo, AirCirc

Category: Tags: ,

With the Ellipticor family a long tradition of circular motor structures and their inherent breakup behavior has been broken since one of its key features is an elliptical voice coil and magnet gap. In combination with the powerful SD AirCirc magnet system the 18WE has high sensitivity, very low distortion, and has an extremely fast response to transients. Above all a TRUE TO LIVE sound which makes 18WE/4542T00 one of the very best midwoofers on the market!

Reviews:
Klang & Ton (GER), 02-2018
Voice Coil, 04-2018

DIY Kits:
Ellipticor One (D3404/552000, 18WE/4542T00)




Weight 2 kg
Product Families

Ellipticor

Product Categories

Midwoofer


- Elliptic voice coil
- Very low mechanical losses
- High sensitivity (SPL)
- AirCirc optimized magnetsystem
- Exceptionally low distortion
- Flexible appearence with replaceable decor ring

  Size:18 cm
  Fs:46 Hz
  Re:3.4 Ω
  Qt:0.25
  Sensitivity:92.5 dB
  VAS:17.2 ltr.
  Sd:133 cm²
  Bl:8.1 Tm
