D3404/552000

~38 mm Dome Tweeter, 4 ohm, Neo, AirCirc

Category: Tags: ,

With the Ellipticor family a long tradition of circular motor structures and their inherent breakup behavior has been broken since one of its key features is an elliptical voice coil and magnet gap. In combination with the powerful SD AirCirc magnet system the D3404 has high sensitivity, very low distortion, and has an extremely fast response to transients. Above all a TRUE TO LIVE sound which makes D3404/552000 one of the very best tweeters on the market!

Reviews:
Voice Coil, 04-2018
Klang & Ton (GER), 02-2018

DIY Kits:
Ellipticor One (D3404/552000, 18WE/4542T00)
Ellipticor-3 (D3404/552000, 18WE/8542-T00, 21WE/8542-T00, 32W/4878-T11)




Weight 0.9 kg
Product Families

Ellipticor

Product Categories

Tweeter


- Elliptic voice coil
- AirCirc optimized magnetsystem
- Low mechanical losses
- Exceptionally low distortion
- High sensitivity (SPL)
- Flexible optics with replaceble decor ring

  Size:2.8 cm
  Fs:475 Hz
  Re:3 Ω
  Qt:0.57
  Sensitivity:97 dB
  VAS:0.04 ltr.
  Sd:11.4 cm²
  Bl:2.8 Tm
