R2604/833000

26mm Ring Radiator 4ohm, Double Ferrite Magnet, Chamber

Category: Tags: ,

The Discovery series offer traditional design, superior sound, a solid construction, and a wide range of variants. Combining these elements – plus a wealth of technical features and finesses – it gives our customers the possibility of acquiring a tailor-made Scan-Speak solution with very good performance at a reasonable low price point!

DIY Kits:
DISCOVERY-FOUR (R2604/833000, 18W/8535-01, 22W/8534G00, 26W/8534G00)
Ellam Discovery 15 (R2604/833000, 15W/8434G00)




Weight 1 kg
Product Families

Discovery

Product Categories

Tweeter


- Extended Frequency To Above 40KHz
- Very Low Resonance Frequency - 450Hz
- Low Distortion
- High sensitivity - 92dB
- Dual Ring Radiator diaphragm (Patent)
- Wave-guide center plug (Patent)

  Size:2.6 cm
  Fs:440 Hz
  Re:2.9 Ω
  Qt:0.38
  Sensitivity:92 dB
  VAS:0.02 ltr.
  Sd:5.4 cm²
  Bl:2.3 Tm
