26W/4867T00

26cm Woofer 4ohm, Alu Cone, Ferrite Magnet

Category: Tags: ,

The Revelator woofers and subwoofers features very rigid cones in paper or aluminium that operates as a piston over a wide frequency range, in combination with Scan-Speaks low-loss linear suspension and the patented Symmetrical Drive (SD-1) it results in very low distortion and a smooth and well behaved frequency response as well as perfect transient reproduction.






Weight 4 kg
Product Families

Revelator

Product Categories

Woofer


- Patented Symmetrical Drive Motor Design
- Rigid Black Anodized Alu Cone
- Low-Loss linear suspension
- Low Damping SBR Rubber Surround
- Die cast Alu Chassis vented below spider
- Ferrite Magnet System w. Rubber Boot

  Size:26 cm
  Fs:18 Hz
  Re:3.7 Ω
  Qt:0.29
  Sensitivity:89 dB
  VAS:220 ltr.
  Sd:320 cm²
  Bl:8.3 Tm
