D2905/990000

28mm Dome Tweeter 6ohm, Ferrite Magnet, Waveguide

Category: Tags: ,

D2905/990000 – The original Revelator tweeter – is build on the heritage of our successful Classic tweeters, continuing with Symmetrical Drive (SD-2) motor design which includes copper caps, the non resonant chamber and the special treated textile 29mm dome and further optimized optimized for the ultimate performance utilizing a large machined aluminium wave guide front.

DIY Kits:
Jensen 1071 (D2905/990000, 18W/8531G00, 26W/8861T00)




Weight 0.9 kg
Product Families

Revelator

Product Categories

Tweeter


- Excellent Sound Reproduction
- 1" Textile Dome Diaphragm
- Patented Symmetrical Drive (SD-2) motor
- Wide Surround Textile Diaphragm
- Large Wave Guide Front
- Black Anodized Mashined Alu Face Plate

  Size:2.8 cm
  Fs:500 Hz
  Re:4.7 Ω
  Qt:0.63
  Sensitivity:91 dB
  VAS:0.02 ltr.
  Sd:8.5 cm²
  Bl:3.5 Tm
